DFAC water truck spray heads

Item

unit

parameter

Vehicle model

CLW5040GPS3 Water Truck

Chassis model

EQ1040TJ20D3

Overall dimensions

mm

5995×2000×2300

Fact cubage

L

1560

Total mass

kg

4495

Curb weight

2875

Rate contained capacity

1490

Body internal dimensions

mm

3000×1100×700

Wheel base

3300

F/R suspension

1032/1663

Approach/departure angle

°

19/13

Exhaust/kw

ml/kw

2659/66

Max speed

km/h

90

Tire specification

7.00-16,6.50-16

Engine type

CY4102-C3F

Traction system

4×2

transmission

5-speed with over drive

Number of axles

2

Electric system

24v

Operation control  system

Electrically hydraulic control

Allowable passengers in cab

2

Equipment

Equipped with front(rear,side)sprinkler(sprinkling width14m )

Equipped with rear working platform with water cannon (range28m)

Equipped with CLW pump(suction lift6m)

Equipped with fire valve,water valve,and filter gauze

Engine

GuangXi YuChai diesel engine

Production cycle

15-17 days

Warranty

12 month,from the date of supply
