Quick Details

  • Drive Wheel: 4x2
  • Fuel: Diesel
  • Transmission Type: Manual
  • Condition: New
  • Sprinkling Area (m): 12 - 16m
  • Emission Standard: Euro 3
  • Engine Capacity: 4 - 6L
  • Tank Volume: 10001 - 15001L
  • Dimensions (L x W x H) (mm): 8800,8500*2400*3000
  • Brand Name: clw
  • Place of Origin: Hubei, China (Mainland)
  • Model Number: CLW5161GSS3
  • Gross Vehicle Weight: 16000

Packaging & Delivery

Packaging Details NUDE WITH WAXING
Delivery Time 25DAYS SINCE WE RECEIVE YOUR ADVANCED PAYMENT

Specifications

1. RHD &LHD
2. Factory outlet
3. High quality , competive price
4. with 3C cirtificate

1. RHD &LHD
2. Factory outlet
3. High quality , competive price
4. with 3C cirtificate



The specification of Dongfeng Tianjin water spraying truck :

Vehicle moderCLW5161GSS3  Body inernal dimension(mm)
Overall dimension(mm)8800,8500×2400×3000 G.V.W(Kg)16000
Load capacity(kg)9500Curb weight(Kg)6305
Engine modelEngine manufacrurerEmissionPower

B190 33

Dongfeng cummins diesel engine Co., LTD

5900

140

Axle number 2Axle load(Kg)

6000/10000

Rear wheel distance(mm)1800,1860Front wheel distance(mm)1880
Tyre specification9.00-20,9.00R20,10.00-20,10.00R20 Wheelbase(mm)

5000,4700

Special Purpose Function&Technical Patameters

Special



purpose



function

1, basic component :antirust tank, connecting device, special self suction sprinkler pump, pipeline, spray outlet, work platform



2, tank body adopts high quality carbon steel plate produced in WISCO, using a large machine molding, junction of the tank head and body using advanced arc welding process.



3, standard configuration: forward on, side spray; high position side sprinkler; rear working platform,with virescence sprinkler gun, the sprinkler gun can rotate 360 degrees, adjustable into column,range≥28m, also can be adjusted into mist, range ≥ 15m, vertical suction process 7M.



4, functional use: widely used in sprinkler, spray, cooling, dust removal, flushing dust booties, spray pesticides,motor pump station,etc.



5,optional configuration: medicine wheel, drug pump, tank anti-corrosion rust-proof, multi-directional water joints, electromagnetic valve, pneumatic valve.

                             Technical       patameters

Sprinkling width (m)                14
Sprinkling range (m)28
Vertical suction  (m)7
Water pump lifts (m)90
time of drawing water (min)5
quantity of flow(m3/h)90

We highly recommend this water spraying truck .



It’s in an excellent condition and as it was made by CLW, you can trust on driving it with high stability.

Since our inspection is very strict, all of our trucks’ durability is very long.



We have many connections with truck companies internationally. So if you want some other model than this truck

We are sure that we can find one that is suitable for you.



\The above information is just for your reference. We can manufacture the trucks as per your request,Please feel free to contact us via email or phone if you have any inquiries.
