Quick Details
- Drive Wheel: 6x4
- Fuel: Diesel
- Transmission Type: Manual
- Condition: New
- Sprinkling Area (m): > 16 m
- Emission Standard: Euro 3
- Engine Capacity: > 8L
- Tank Volume: 10001 - 15001L
- Dimensions (L x W x H) (mm): 7500*2480*3150
- Brand Name: Chengli
- Place of Origin: Hubei, China (Mainland)
- Model Number: CLW water tower fire truck
- Gross Vehicle Weight: 25000
- Certification: BV ISO CCC
- Warranty: 12 months
- After-sales Service Provided: Overseas third-party support available
- Color: Red
- Chassis brand: Dongfeng Foton Forland Howo Faw
- Name: water tower truck
- Product name: 12m3 volume 18 meters working height water tower fire truck
- Tank material: Stainless Steel
- Storage: water /foam
- Drive type: 6x4
- Volume: 5000L 6000L 8000L 10000L
- Chassis: HOWO also other brand new
- monitor max working height: 18m,22m,28m
Packaging & Delivery
| Packaging Details | naked with waxing |
|---|---|
| Delivery Time | 50 days |
12m3 volume 18 meters monoitor working height water tower fire truck
Descriptions | parameter | ||
|
|
| |
General | GVW/Curb weight | 29000kg/13050kg | |
| Rate of load | 15000kg | |
| Overall size | 9900×2500×3500 | |
cab | Cab | Flat head, double-row, four doors, hydraulic tilt cab,2+4 seat, 4 Set of safety belt in the back seats. Manual window | |
| Siren control system | Yes | |
| Air conditioner | Yes | |
| Drive type | 6x4 left hand drive | |
| Fuel type: | Diesel | |
| Engine manufacturer/model | WEICHAI/ WD615.69 | |
| Power | 247kw/336hp | |
| Displacement | 9726ml | |
| Emission standard | Euro 2 | |
Chassis | Engine type | Inline six cylinder, four-stoke, water-cooled, turbocharged and intercooled, fuel direct injection pump. | |
| Shift box | 9-speed Forwarder with 2 Reverse | |
| Brake | Air brake | |
| Wheelbase | 4325+1350 | |
| No. of axle/payload | 3/7000kg/16000kg | |
| Tire specification/No. | 11.00-20/10+1 | |
| Max speed | 85km/h | |
| Paint color | Red paint | |
Special configuration | Water Tank capacity | 10,000L Made in high-strong carbon steel with anti-corrosion | |
| Foam tank capacity | 2000L Made in high quality steel with anti-corrosion | |
| Consist of crew compartment, water tank (body), pump house, equipment compartments, water and foam pump system, fire monitor, electronic sirens, lights and fire equipment. | ||
| This truck is improved and refitted with chassis of HOWO. It is equipped with foam spraying fire system. The spacious cabin is suitable for six crews. Its internal structure reasonable and compact its foam spraying fire system could be used signally or jointly | ||
| Atmospheric pressure pump fire pump: CB10/60 @ 1.0Mpa,Leading water time ≤ 50s, within water depth 7m | ||
| Fire monitor Model: PL48(dual-purpose gun blisters) Water range ≥ 55m/1.0MPa , foam range: ≥ 50m/1.0MPa | ||
18 meters monoitor(We also can make 25 meters,28 meters )
working height
Technical Data for monitor sky lifting function | |||
Max. Working Height | 18m(22m,25m,28m can be chose) | Outrigger Span | 2350mm |
Max. Working Radius | 6.5m | Rotation Angle | 360° |
Max Luffing Angle of Boom | 85° | Rated Pressure Of Hydraulic System | 16Mpa |
Max Luffing Angle of Forearm | 155° | Max Oil Flow Of Hydraulic System | 30L/min |
Safety Performance | · On and off interlock device | ||
| · Turntable indication device | ||
| · Boom and forearm interlock device | ||
| · Rotation limit device | ||
| · System does not work after power failure | ||
| · Soft leg alarm function | ||
| · Boom and forearm Angle Mechanical limit device | ||
We use famous brand new chassis to bulid water tower truck(such as Beiben,HOWO,Dongfeng,Foton,IVECO)
Water tower fire truck fight fire in fireground
Our company passed ISO9001-2008 Quality Management system certificate,ISO 14001 Enviromental Management system certiifcate,OHSAS18001 Occupational health and safty management system certificate,Europen ADR certificate,ASME certificate OCAP,BV and so on certificate
1. Factory Supply:
one of the biggest special purpose truck manufacturers in china,
more than 300 kinds of special truck for your choice.
2. OEM Ability: according to your demand, material, dimensions, surface color and the logo are optional for you.
3. Good Quality: with ISO CCC BV certification
Solid technology, advanced equipments; reliant quality and flexible modes of operation also have strict quality control system,
passed the ISO9001-2008 and the 3C (China Compulsory Certification),
our brand is china famous brand with good reputation in the market.
4. Best Service: 24-hour hotline and email during communication.
5. Fast Delivery: 5-10 days after payment(most common products), safe and quick delivery.
Chengli Special Automobile Co.,Ltd.
Our company has total assets of 2 billion Yuan(About 0.32 billion USD), covers an area of more than 1,000 acres, has more than 8,000 employees, including 500 technical engineers, more than 2,000 skilled workers, annual production capacity of 100,000 sets special puporse vehicles .
We has leading products as: water truck, garbage truck, suction sewage truck, sweeper,oil tanker truck, chemical trucks, wrecker,aerial platfrom truck , fire truck,crane truck, refrigerated trucks, vans,LPG pressure vessels, road maintenance trucks, flatbed trucks, bulk food truck, dry mortar vehicles, beekeeping truck,mobile stage vehicles,LED advertisement trucks, mobile shop trucks, heavy duty truck mounted crane, cement pump truck, pharmaceuticals transportation trucks, all kinds of trailers,etc., covers series of more than 800 models.,
Naked, waxing on roro or bulk ship or by 20GP,40GP,40HQ,40FR and so on
Question 1: How many units is your factory MOQ?
Our MOQ is 1 unit .
Question 2: What is the shortest production time?
Our production time is 15 days for one unit(common products), if you need more than 5 or more than 10, we can offer you in 40days .
Question 3: How long time of your warranty?
Our warranty is one years after send to your country .
Question 4: What certificate do you have?
All our products has orignal certificate and CCC and ISO certificate ,we accept SGS and BV identification.
Question 5: Do you make right hand drive trucks?
Yes,we do. Our standard Steering:Left-hand drive, if you need Right-hand drives, please inform us in advance.
Qustion 6: Where is your factory?Near Shanghai ,Guangzhou ,or Beijing?
Our factory is in central China,You can take plane to Wuhan airport from Shanghai ,Guangzhou ,or Beijing.(According to your journey).The distances between each these 3 cities to Wuhan are nearly the same. When you arrive Wuhan City,we can arrange driver to pick you up at Wuhan airport.It takes nearly 2 hours from Wuhan airport to our factory.
